• Concrete recycling plant for environment protection and for the exploitation of raw materials recovered from residual concrete and water of truck-mixers, concrete pumps, concrete Batching Plant plants, concrete transporting hoppers and buckets.
• Normal concrete wash-out per hour up to 11 m3
• Normal mortar wash-out per hour up to 4 m3
• Separation :
  • o slurry water = 0 - 0.15 mm.
  • o solid materials = 0.15 - 50 mm.
• Washing drum designed for the reception and extraction of solid materials, consisting oftwo bolted sections, made of special steel, complete with supporting legs with dischargingopening for slurry water overflowing.
• Lateral opening with overflow slurry water discharge
• Extraction spiral installed inside the drum, made of 10 mm. thickness steel, supportedinthe front by roller
• Type bearing; drive unit placed in the rear side, with planetary type gearbox directly coupled to electric motor power 5.5 Kw.
• Electric control panel for manual operating cycle, control panel is water proof supported by a steel column with synoptic panel, lights and buttons ,suitable for the automatic operation of washing spiral.

FEATURES

• Complete recovery of water and aggregate
• Zero waste
• Green concept
• Compact footprint
• Clean disposal of waste concrete and washed residu
